Tilt Tray Sorter for Lightweight ItemsLINISORT® S-C
Space-saving piece sorter that automates sorting operations
- Purpose
- Sorting
- Industries
- Transportation, Logistics, Food, Apparel, Cosmetics, Toys, Banking
Features
-
1
Space-saving
Multi-tier design enables space-saving operation
Minimum unit (30 chute)
Requires only 25 m² of installation space -
2
Easy installation
Caster-mounted design allows easy installation and relocation
The minimum unit can typically be installed in about one day.
-
3
High throughput with low noise
Linear motor drive ensures quiet and energy-efficient operation.
Sorting Capacity: Up to 4,800 items/hour
Standard Specifications
| Single-Tier Configuration | Two-Tier Configuration | |
|---|---|---|
| Sorting Capacity | Maximum 2,400 items/hour | Maximum 4,800 items/hour |
| Sorting Items | Daily necessities, groceries, apparel, mail, cosmetics, pharmaceuticals, toys, games, etc. | |
| Sorting Size (mm) | Maximum: L450 × W350 × H50 Minimum: L100 × W100 × H10 |
|
| Sorting Weight | 0.1 to 2 kg | |
| Feeding method | Manual / Automatic (via conveyor) | |
| Drive System | Linear motor drive | |
| Power Supply | AC 200/220V, 50/60Hz | |
